The Quick DUKE horizontal windlass is a powerful anchoring equipment designed for boats 18-26 meters in length. It operates with a 3000W motor power and 24V voltage.
| Motor Power | 3000W |
| Voltage | 24V |
| Gypsy | 16 mm |
| Maximum Pull | 3000 kg |
| Maximum Working Load | 1200 kg |
| Working Load | 600 kg |
| Amperage at Working Load | 185A |
| Winding Speed | 24 m/min. |
| Winding Speed (at Working Load) | 14 m/min. |
| Suitable Boat Length | 18-26 m |
Its construction utilizes AISI 316 stainless steel, aluminum, chrome plating, and composite materials. It is CE certified, and the necessary sensor for an optional chain counter connection is mounted as standard. The solenoid and winch handle are among the standard equipment.
...
...
