Quick DUKE vertical windlass is a powerful anchoring equipment designed for boats with a length of 22 to 29 meters. It operates with 24V voltage and a 3500W motor power.
| Motor Power | 3500W |
| Voltage | 24V |
| Gypsy Diameter | 14 mm |
| Maximum Pulling Capacity | 4000 kg |
| Maximum Working Load | 1500 kg |
| Working Load | 700 kg |
| Amperage at Working Load | 225A |
| Winding Speed (No Load) | 24 m/min. |
| Winding Speed (at 700 kg Load) | 14 m/min. |
| Suitable Boat Length | 22-29 m |
Its construction utilizes AISI 316 stainless steel, aluminum, chrome plating, and composite materials. Sensor, solenoid, and winch handle for the optional chain counter connection are standard equipment.
