Quick GENIUS GP2 1500 horizontal windlass without gypsy, with a 500 W motor power and 12 V supply, is designed for anchoring and mooring systems on boats with a length of 6-10 m. With its 6 mm gypsy, it is compatible with 6 mm DIN766 and 6 mm ISO chains.
| Model | GP2 1500 |
|---|---|
| Motor Power | 500 W |
| Voltage | 12 V |
| Maximum Pull | 680 kg |
| Maximum Working Load | 250 kg |
| Working Load | 85 kg |
| Current at Working Load | 76 A |
| Winding Speed (No Load) | 25.5 m/min |
| Winding Speed (at Working Load) | 10.3 m/min |
| Gypsy | 6 mm |
| Suitable Boat Length | 6-10 m |
The windlass body is made of anodized aluminum hard oxide. AISI 316 stainless steel, aluminum, chrome plating, and composite materials are used. The series, produced with a stainless steel gypsy and gypsy cover, has options for versions with or without a gypsy.
- Horizontal windlass design
- Anodized aluminum hard oxide body
- Options for versions with or without gypsy
- Stainless steel gypsy and gypsy cover
- Capability to pull 12/14/16 mm rope with chain gypsy
- Chain pressure bar
- IP66 class waterproof motor
- Epicyclical gearbox
- 6 mm gypsy: Suitable for 6 mm DIN766, 6 mm ISO chains
- 8 mm gypsy: Suitable for 8 mm DIN766, 8 mm ISO, 5/16" BBB chains
The product is CE certified. The necessary sensor for the optional chain counter connection is mounted as standard on the windlass. Solenoid and remote control are among the standard equipment.
...
...
