Quick GENIUS GP2 2000 is a horizontal windlass without a gypsy, designed for use on boats with a length of 8-13 meters, featuring an 800 W motor power and 12 V supply.
| Model | GP2 2000 |
|---|---|
| Motor Power | 800 W |
| Voltage | 12 V |
| Maximum Pull | 900 kg |
| Maximum Working Load | 350 kg |
| Working Load | 120 kg |
| Amperage at Working Load | 96 A |
| Retrieval Speed | 29.6 m/min |
| Retrieval Speed (at Working Load) | 20 m/min |
| Gypsy | 8 mm |
| Suitable Boat Length | 8-13 m |
The body structure utilizes AISI 316 stainless steel, aluminum, chrome plating, and composite materials. It features an anodized aluminum hard oxide body, a stainless steel gypsy, and a gypsy cover. It is CE certified.
It comes with an IP66 class waterproof motor, an epicyclical gearbox, a chain stripper bar, and a chain gypsy. The solenoid and windlass handle are standard equipment. The necessary sensor for the optional chain counter connection is mounted as standard on the windlass.
- Horizontal windlass design
- Options for versions with or without a gypsy
- 8 mm gypsy
- 6 mm gypsy: Suitable for 6 mm DIN766 and 6 mm ISO chains
- 8 mm gypsy: Suitable for 8 mm DIN766, 8 mm ISO, and 5/16" BBB chains
- Capability to retrieve 12/14/16 mm rope with the chain gypsy
...
...
