The Quick HECTOR horizontal windlass without gypsy is a model that operates with a 1000W motor power and 24V supply, featuring an 8 mm chain gypsy. It is suitable for boats in the 10-13 meter length range.
Its body is manufactured from anodized aluminum and composite material. AISI 316 stainless steel, aluminum, chrome plating, and composite components are used. It is CE certified.
- Model: Quick HECTOR, without gypsy
- Type: Horizontal windlass
- Motor power: 1000W
- Voltage: 24V
- Gypsy: 8 mm
- Maximum pull: 1100 kg
- Maximum working load: 490 kg
- Working load: 160 kg
- Current at working load: 80A
- Winding speed (no load): 39.6 m/min
- Winding speed (at working load): 21 m/min
- Suitable boat length: 10-13 m
- Anodized aluminum / composite body
- Series available with or without gypsy; this model is without gypsy
- Capability to pull 14/16/18 mm rope with the chain gypsy
- Manual release system
- Chain stripper bar
- Integrated solenoid unit
- IP66 class waterproof motor
- 8 mm gypsy: suitable for 8 mm DIN766, 8 mm ISO, 5/16" G4, 5/16" BBB chains
- 10 mm gypsy: suitable for 10 mm DIN766, 10 mm ISO, 3/8" G4 chains
- 12/13 mm gypsy: suitable for 12 mm ISO, 13 mm DIN766 chains
- Sensor for optional chain counter connection is standard mounted on the windlass
- Solenoid and remote control are standard equipment
...
...
