Quick HEROES 1700 is a horizontal windlass powered by 24V with a power of 1700W. It is an anchor windlass solution designed for boats in the 12-16 m range, with a 10 mm gypsy.
| Model | HEROES 1700 |
|---|---|
| Power | 1700W |
| Voltage | 24V |
| Gypsy | 10 mm |
| Maximum Pull | 1700 kg |
| Maximum Working Load | 500 kg / 600 kg |
| Maximum Retrieval Speed | 24.2 / 34.5 m/min |
| Weight without Drum | 59 kg |
| Weight with Drum | 66 kg |
| Suitable Boat Length | 12-16 m |
The windlass body is made from AISI 316 stainless steel, aluminum, chrome plating, and composite materials suitable for the marine environment. It is CE certified, and the necessary sensor for an optional chain counter connection is standardly mounted on the windlass. The integrated solenoid and winch handle are among the standard equipment.
- Horizontal windlass design
- White (RAL9010) painted aluminum body
- Option with or without drum
- Capability to pull rope with chain gypsy
- Integrated solenoid
- Manual retrieval system
- Manual free-fall system
- Secure mechanical brake
- IP66 rated protected motor
- Gearbox with anodized aluminum housing
- 10 mm gypsy: Suitable for 10 mm DIN766, 10 mm ISO, 3/8" G4, 3/8" BBB chains
- 12/13 mm gypsy: Suitable for 12 mm ISO, 13 mm DIN766, 7/16" G4 chains
- 14 mm gypsy: Suitable for 14 mm DIN766, 1/2" G4 chains
...
...
