Quick HEROES 2300 is a horizontal windlass with a power of 2300W and a 24V supply. It operates with a 12/13 mm gypsy and is designed for boats in the 15-20 meter length range.
| Model | Heroes 2300 |
|---|---|
| Power | 2300W |
| Voltage | 24V |
| Gypsy | 12/13 mm |
| Maximum Pull | 2400 kg |
| Maximum Working Load | 850 kg |
| Maximum Retrieval Speed | 29.9 m/min |
| Weight without Drum | 64 kg |
| Weight with Drum | 71 kg |
| Suitable Boat Length | 15-20 m |
The windlass body is manufactured from AISI 316 stainless steel, aluminum, chrome plating, and composite materials suitable for marine conditions. It features a white (RAL9010) painted aluminum body and a gearbox with an anodized aluminum housing.
- Horizontal windlass design
- Option for use with or without a drum
- Capability to pull rope with a chain gypsy
- Integrated solenoid
- Manual retrieval system
- Manual free-fall system
- Safe mechanical brake
- Motor with IP66 protection class
- CE-approved construction
- A sensor for optional chain counter connection is standardly mounted on the windlass
Gypsy and chain compatibilities:
- 10 mm gypsy: Compatible with 10 mm DIN766, 10 mm ISO, 3/8" G4, 3/8" BBB chains
- 12/13 mm gypsy: Compatible with 12 mm ISO, 13 mm DIN766, 7/16" G4 chains
- 14 mm gypsy: Compatible with 14 mm DIN766, 1/2" G4 chains
...
...
