The Quick Tumbler capstan is a 1000 W, 12 V winch with a 130 mm drum diameter. It is offered with specified technical values for a maximum pulling capacity of 1000 kg and a boat length range of 11-18 m.
| Technical Specification | Value |
|---|---|
| Power | 1000 W |
| Drum diameter | 130 mm |
| Voltage | 12 V |
| Maximum pull | 1000 kg |
| Maximum working load | 370 kg |
| Working load | 120 kg |
| Current at working load | 140 A |
| Winding speed | 30.1 m/min. |
| Winding speed (at working load) | 15.5 m/min. |
| Suitable boat length | 11-18 m |
The housing is manufactured from AISI 316 stainless steel, aluminum, chrome plating, and composite materials. It is CE certified and includes a solenoid as standard equipment.
- Stainless steel housing
- Bronze drum with chrome plating
- IP67 rated waterproof motor
...
...
